iSMA-D-PD User Manual


Introduction

The iSMA-D-PD10C-B1 is 10.1'' is an industrial LCD panel, which has been designed to simplify the use of MAC36 controllers, iSMA-B-MAC36NL and iSMA-B-MAC36PRO.

The LCD panel is equipped with multiple interfaces to accelerate the connection with the master controller. The applied RJ45 interface provides transmitting touch commands (RJ45-USB).

The 16:9 aspect ration with 1366x768 resolution allows for displaying graphics clearly.

The panel is VESA compliant and can be wall-mounted. It has an extensive menu in 7 languages.

Available with EU, UK, and US power supply.

iSMA-D-PD10C-B1 panel connected to the iSMA-B-MAC36NL controller

Revision History

Rev.DateDescription
1.310 Nov 2023iSMA-B-MAC36PRO references
1.225 May 2022Rebranded
1.131 Mar 2020Company data update
1.028 Aug 2015First edition
