iSMA-D-PD User Manual
Introduction
The iSMA-D-PD10C-B1 is 10.1'' is an industrial LCD panel, which has been designed to simplify the use of Master Application Controller, iSMA-B-MAC36NL.
The LCD panel is equipped with multiple interfaces to accelerate the connection with the master controller. The applied RJ45 interface provides transmitting touch commands (RJ45-USB).
The 16:9 aspect ration with 1366x768 resolution allows for displaying graphics clearly.
The panel is VESA compliant and can be wall-mounted. It has an extensive menu in 7 languages.
Available with EU, UK, and US power supply.
iSMA-D-PD10C-B1 panel connected to the iSMA-B-MAC36NL controller
Revision History
| Rev. | Date | Description |
|---|---|---|
| 1.0 | 28 Aug 2015 | First edition |
| 1.1 | 31 Mar 2020 | Company data update |
| 1.2 | 25 May 2022 | Rebranded |
Revision history
