Introduction
The iSMA-D-PD10C-B1 is 10.1'' is an industrial LCD panel, which has been designed to simplify the use of MAC36 controllers, iSMA-B-MAC36NL and iSMA-B-MAC36PRO.
The LCD panel is equipped with multiple interfaces to accelerate the connection with the master controller. The applied RJ45 interface provides transmitting touch commands (RJ45-USB).
The 16:9 aspect ration with 1366x768 resolution allows for displaying graphics clearly.
The panel is VESA compliant and can be wall-mounted. It has an extensive menu in 7 languages.
Available with EU, UK, and US power supply.
iSMA-D-PD10C-B1 panel connected to the iSMA-B-MAC36NL controller
Revision History
|
Rev. |
Date |
Description |
|---|---|---|
|
1.3 |
10 Nov 2023 |
iSMA-B-MAC36PRO references |
|
1.2 |
25 May 2022 |
Rebranded |
|
1.1 |
31 Mar 2020 |
Company data update |
|
1.0 |
28 Aug 2015 |
First edition |
Revision history
