Introduction

The iSMA-B-2D device has been built in order to control the light in a single space in the building. The device is designed for controlling two separate DALI light areas with up to 32 DALI ballasts (16 ballasts for each DALI interface). Two built-in special inputs and two digital inputs are designed to connect the presence detectors and light switches. A dedicated DIP switch allows for activating a predefined inputs configuration. The device allows for controlling DALI ballasts by a common light switch and a common presence detector without the need of programming, which makes the device a unique plug & play type device designed for DALI network control.

2D controller

Revision History


Rev.

Date

Description

1.0

29 Mar 2021

First edition

1.1

4 May 2021

New renders

1.2

25 May 2022

Rebranded; corrections in the Sensors and Switches section (digital input number)

Revision history
